SHOP MANUAL
Engine
Ch 1 page 154
12. Position the O-ring in the lid. Renew the
O-ring if it is at all damaged.
13. Assemble the parts and tighten the rotor nut
by hand.
14. When tighten the rotor axle (point 15) its neccesarry to
modified the Socket spanner 8023 with to weld nut M20 without
threads,
on the square end.
See figure 309.
The socket spanner 8023 is still usable for the old type of the cen-
trifugalfilter after this modification
Figure 308
Figure 309
