SHOP MANUAL
TRANSMISSION
Ch 2 page 28 Ch 2 page 29
TRANSMISSION
Remove the pins
Hang the cabin in the 04 hook points (fig.37) on the top of it and remove
the cabin (fig.38)
Measure distance between the rear side of T/M and the frame (use this
as reference when assembling the new one)
Figure 36
Figure 37
Figure 38
Figure 39
