SHOP MANUAL
TRANSMISSION
Ch 2 page 36 Ch 2 page 37
TRANSMISSION
Insert fixing plate (1) into the transmission housing and lock
the speed sensor (2) with the wiring harness plug.
Bring seal (1) and cover (2) into contatc positin at the
transmission housing.
Fix cover with cylindrical screws (1).
Tightening torque (M8/8.8x16) MA = 23 Nm
Figure 64
Figure 63
Figure 65
