SHOP MANUAL
TRANSMISSION
Ch 2 page 52 Ch 2 page 53
TRANSMISSION
Fit hexagon screw (1) and fix the breather with clip to the
transmission housing using a cylindrical screw.
Tightening torque (M30/10.98x150) MA = 1900 Nm
We recommend to tighten the hexagon
screws with a power wrench.
(S) Power wrench
Tightening torque (M30/10.98x150) MA = 1900 Nm
Figure 121
Figure 120
