SHOP MANUAL
TRANSMISSION
Ch 2 page 62 Ch 2 page 63
TRANSMISSION
Assemble the body heating assemble (if it was assembled on the ma-
chine)
Assemble 04 screws on exhaust pipe clamps
Assemble the body heating bracket. (04 screws)
Assemble the clamp of the hinge bearing lubrication from the body
heating bracet.
Remember to re-check the hydraulic level after turning ON the machine after the transmission replacement
CAUTION
Figure 158
Figure 157
Figure 159
