SHOP MANUAL
DRIVE LINE
Ch 3 page 82 Ch 3 page 83
DRIVE LINE
By crane, turn the axle housing 90°
By crane, carefully lift the differential out from
the axle housing
Assemble 2 pcs. M16 eye bolt to the M16 threaded hole in the
bearing housing
Disassemble screws from the differential flange
Figure 219
Figure 218
Figure 217
Figure 216
