SHOP MANUAL
DRIVE LINE
Ch 3 page 108 Ch 3 page 109
DRIVE LINE
Assemble the cover.
Screw: M10x40 ISO4017-8.8 fzb
Locking liquid: Loctite 245
Torque limit 46 Nm
Apply sealing compound: Loctite 574.
Apply on both sides of the holes.
Figure 306
Figure 305
Figure 304
Figure 303
