SHOP MANUAL
DRIVE LINE
Ch 3 page 146 Ch 3 page 147
DRIVE LINE
Fasten the brakehose to the frame.
Torque limit: 136 Nm
Fill oil to the axle housing,
Oil: Spirax S3 ALS 80W-90. (For fluid type and specifications, re-
fer to the DOOSAN Operating & Maintenance Manual Chapter 6)
the machine should be placed on a horizontal ground.
Check the oil level on the tandem housing.
Figure 448
Figure 447
Figure 446
Figure 445
