Ch 6 page 57
ELECTRICAL SYSTEM
SHOP MANUAL
The sensor group includes:
Coolant temperature sensor, T33
Charge air pressure sensor, T47
Charge air temperature sensor, T47
You can make an aid from
steel wire, see illustration, to
make it easier to remove the
connectors from the control
unit.
Figure 41
Figure 44
Figure 42
Figure 43
