SHOP MANUALSHOP MANUAL
FRONT WAGON
Ch 7 Page 18 Ch 7 Page 19
FRONT WAGON
Measure outer rings and inner ring.
Insert seal rings to outer rings and lubericate them with
grease. The seal rings must be assembled correctly for
maximum and proper lubrication flow.
Figure 40
Figure 37
Figure 39
Figure 38
Measuring details on page 20 - 21
NOTE
To Next Page
