SHOP MANUALSHOP MANUAL
FRONT WAGON
Ch 7 Page 48 Ch 7 Page 49
FRONT WAGON
To access the valves to fill the system with freon gas or water to the heat system, remove the rear cover on the
right side. Then is possible to reach the connectors. The air conditioning filter can be accesed from this way
The air heating filter can be accessed from outside the cab, right side. Opened the small window, can remove it
filter to clean or replace.
Figure 107
Connectors
Air conditioning filter
