SHOP MANUALSHOP MANUAL
ERROR CODES LIST
Ch 10 Page 4
Ch 10 Page 5
ERROR CODES LIST
658 5 Injector Cyl. #8 - Current below normal or open circuit
658 6 Injector Cyl. #8 - Current above normal or grounded circuit
658 7 Injector Cyl. #8 - Mechanical system not responding properly
677 0 Starter Motor Relay - Above normal operational range
677 2 Starter Motor Relay - Erratic, intermittent or incorrect
677 3 Starter Motor Relay - Voltage above normal or shorted high
677 4 Starter Motor Relay - Voltage below normal or shorted low
677 5 Starter Motor Relay - Current below normal or open circuit
677 7 Starter Motor Relay - Mechanical system not responding properly
677 8 Starter Motor Relay - Abnormal frequency, pulse width or pending
986 2 Requested Percent Fan Speed - Erratic, intermittent or incorrect
986 3 Requested Percent Fan Speed - Voltage above normal or shorted
high
986 4 Requested Percent Fan Speed - Voltage below normal or shorted
low
986 5 Requested Percent Fan Speed - Current below normal or open
circuit
986 7 Requested Percent Fan Speed - Mechanical system not responding
properly
1110 2 Engine Protection System has Shutdown Engine
1239 7 Engine Fuel Leakage
1322 7 Engine Misre for Multiple Cylinders
1323 7 Engine Misre Cylinder #1
1324 7 Engine Misre Cylinder #2
1325 7 Engine Misre Cylinder #3
1326 7 Engine Misre Cylinder #4
1327 7 Engine Misre Cylinder #5
1328 7 Engine Misre Cylinder #6
1329 7 Engine Misre Cylinder #7
1330 7 Engine Misre Cylinder #8
1442 2 Fuel Valve Position - Erratic, intermittent or incorrect
1442 3 Fuel Valve Position - Voltage above normal or shorted high
1483 2 Source Address of Controlling Device for Engine Control - Erratic
1632 2 Engine Torque Limit Feature - Erratic
1639 4 Fan Speed - Voltage below normal or shorted low
1761 0 SCR Catalyst Tank Level - Above normal operational range
1761 1 SCR Catalyst Tank Level - Below normal operational range
1761 3 SCR Catalyst Tank Level - Voltage above normal or shorted high
1761 6 SCR Catalyst Tank Level - Current above normal or grounded
circuit
1761 8 SCR Catalyst Tank Level - Abnormal frequency, pulse width or
pending
2797 2 Engine Injector Group 1 - Erratic, intermittent or incorrect
2797 3 Engine Injector Group 1 - Voltage above normal or shorted high
2797 4 Engine Injector Group 1 - Voltage below normal or shorted low
2798 2 Engine Injector Group 2 - Erratic, intermittent or incorrect
2798 3 Engine Injector Group 2 - Voltage above normal or shorted high
2798 4 Engine Injector Group 2 - Voltage below normal or shorted low
3031 0 SCR Catalyst Tank Temperature - Above normal operational range
3031 1 SCR Catalyst Tank Temperature - Below normal operational range
3031 3 SCR Catalyst Tank Temperature - Voltage above normal or shorted
high
3031 6 SCR Catalyst Tank Temperature - Current above normal or
grounded circuit
3226 2 Outlet NOx - Erratic, intermittent or incorrect
3226 3 Outlet NOx - Voltage above normal or shorted high
3226 5 Outlet NOx - Current below normal or open circuit
3226 6 Outlet NOx - Current above normal or grounded circuit
3241 2 Exhaust Gas Temperature - Erratic, intermittent or incorrect
3241 3 Exhaust Gas Temperature - Voltage above normal or shorted high
3241 5 Exhaust Gas Temperature - Current below normal or open circuit
3241 6 Exhaust Gas Temperature - Current above normal or grounded
circuit
3360 2 SCR Catalyst Tank Controller - Erratic, intermittent or incorrect
3361 2 SCR Catalyst Dosing Unit - Erratic, intermittent or incorrect
3361 3 SCR Catalyst Dosing Unit - Voltage above normal or shorted high
3361 4 SCR Catalyst Dosing Unit - Voltage below normal or shorted low
3361 6 SCR Catalyst Dosing Unit - Current above normal or grounded
circuit
3363 2 SCR Catalyst Tank Heater - Erratic, intermittent or incorrect
3363 3 SCR Catalyst Tank Heater - Voltage above normal or shorted high
3363 5 SCR Catalyst Tank Heater - Current below normal or open circuit
3363 6 SCR Catalyst Tank Heater - Current above normal or grounded
circuit
4090 0 NOx limits exceeded, cause unknown - High level
4090 2 NOx limits exceeded, cause unknown - Erratic or incorrect
4095 2 NOx limits exceeded due to Interrupted Reagent Dosing
4096 2 NOx limits exceeded due to Empty Reagent Tank
4334 0 SCR Dosing Pressure - Above normal operational range
4334 1 SCR Dosing Pressure - Below normal operational range
4334 2 SCR Dosing Pressure - Erratic, intermittent or incorrect
4334 3 SCR Dosing Pressure - Voltage above normal or shorted high
4334 6 SCR Dosing Pressure - Current above normal or grounded circuit
4337 2 SCR Dosing Temperature - Erratic, intermittent or incorrect
4337 3 SCR Dosing Temperature - Voltage above normal or shorted high
4337 6 SCR Dosing Temperature - Current above normal or grounded
circuit
4341 2 SCR Reagent Line Heater - Erratic, intermittent or incorrect
