Hioki 8841 - Page 8

9.14.5 Setting the Current Measurement 211
9.15 Setting the 8947 CHARGE UNIT 212
9.15.1 Acceleration Measurement (Charge/Preamp)
Selection 213
9.15.2 Setting the Sensor Sensitivity
215
9.15.3 Setting the Voltage Measurement
216
Chapter 10 Trigger Functions 217
10.1 Overview of the Trigger Functions 217
10.2 Operation Sequence (Trigger mode setting)
218
10.3 TRIGGER Screen Organization
220
10.4 Trigger Mode
221
10.5 Pre-trigger
222
10.6 Trigger Timing (REC only)
224
10.7 Trigger Source AND/OR Linking
225
10.8 Analog Trigger
226
10.8.1 Level Trigger 226
10.8.2 Window Trigger 229
10.8.3 Voltage Drop Trigger 231
10.8.4 Period Trigger 233
10.8.5 RMS Level Trigger 236
10.9 Logic Trigger 238
10.10 External Trigger Function
240
10.11 Timer Trigger Function
241
10.12 Manual Trigger
244
10.13 Trigger Output Terminal
244
Chapter 11Waveform Display Screen Operation 245
11.1 Scrolling the Waveform 246
11.2 Using the A･B Cursors
247
11.2.1 Using the Line Cursors (Vertical) 248
11.2.2 Using the Line Cursors (Horizontal) 249
11.2.3 Using the Trace Cursors 250
11.2.4 Using the A
･
B Cursors (X-Y Screen)
252
11.3 Magnification/compression Ratio Along the Time
Axis 253
11.4 Zoom Function (MEM only)
254
11.5 Input Level Monitor Function
255
11.6 View Function (VIEW key)
256
11.6.1 Position Display 256
11.6.2 Block Display (MEM only)
257
