Chapter 17. iSCSI configuration 2 - Software Initiator on Red Hat Linux 397

Draft Document for Review August 30, 2007 12:59 am 7065iSCSI_Config2.fm

SESSION STATUS : ESTABLISHED AT Mon Jun 11 19:20:36 EDT 2007

SESSION ID : ISID 00023d000004 TSIH 1e9

*******************************************************************************

[root@hooghly ~]#

/proc/scsi/scsi

If all four iSCSI ports of the DS3300 are used to connect to servers, every logical drive that is

mapped to the host will initially be seen 4 times before the MPP driver combines them and

shows only one disk to the user. This information can be found in the file /proc/scsi/scsi, which

shows SCSI devices that are detected by the Linux kernel. See Example 17-17. SCSI port 5,

6, 7, 8 are the iSCSI connections to the iSCSI ports of the DS3300. Both LUNs (0 and 1)

appear on each SCSI port as well as the Access LUN also called Universal Xport. SCSI port

9 represents the two logical drives configured on the DS3300 that are seen by the user as

physical disks.

Example 17-17 /proc/scsi/scsi

[root@hooghly ~]# cat /proc/scsi/scsi

Attached devices:

Host: scsi0 Channel: 00 Id: 00 Lun: 00

Vendor: TEAC Model: FD-05PUB Rev: 2000

Type: Direct-Access ANSI SCSI revision: 02

Host: scsi1 Channel: 00 Id: 00 Lun: 00

Vendor: TEAC Model: CD-224E Rev: 2.9B

Type: CD-ROM ANSI SCSI revision: 02

Host: scsi2 Channel: 00 Id: 00 Lun: 00

Vendor: ServeRA Model: Drive 1 Rev: V1.0

Type: Direct-Access ANSI SCSI revision: 02

Host: scsi2 Channel: 00 Id: 01 Lun: 00

Vendor: ServeRA Model: Drive 2 Rev: V1.0

Type: Direct-Access ANSI SCSI revision: 02

Host: scsi5 Channel: 00 Id: 00 Lun: 00

Vendor: IBM Model: 1726-3xx FAStT Rev: 0250
