High Voltage SourceMeter Instrument Reference Manual Section 6: Re
2470-901-01 Rev. A / May 2019 6-7
Figure 106: New Buffer Name
5. Select the OK button on the displayed keyboard.
6. The Style dialog box is displayed. You can select:
 Standard: Store readings with full accuracy with formatting, maximum approximately
5,000,000 readings.
 Compact: Store readings with reduced accuracy (6.5 digits) with no formatting information,
1 μs accurate timestamp, maximum approximately 20,000,000 readings. Once you store the
first reading in a compact buffer, you cannot change certain measurement settings, including
range, display digits, and units; you must clear the buffer first.
 Full: Store the same information as standard, plus additional information.
Figure 107: Select the buffer style
