13: Introduction to TSP commands 2470 High Voltage SourceMeter Instrument
13-8 2470-901-01 Rev. A / May 2019
To save the script to nonvolatile memory, send the command:
testInfo.save()
To load a script by sending commands:
1. Send the command loadscript scriptName, where scriptName is the name of the script.
The name must be a legal Lua variable name.
2. Send the commands that need to be included in the script.
3. Send the command endscript.
4. You can now run the script. Send the script name followed by (). For more information, se
e
Running scripts using a remote interface (on page 13-8
).
Running scripts using the front-panel interface
To run a script from the front-panel interface:
1. Press the MENU key.
2. Under Scripts, select Run. The RUN SCRIPTS window is displayed.
3. From the Available Scripts list, select the script you want to run.
4. Select Run Selected.
Running scripts using a remote interface
You can run any script using scriptVar.run(). Replace scriptVar with the name of a script that
is in nonvolatile or run-time memory.
Saving a script to nonvolatile memory
You can save scripts to nonvolatile memory. To keep a script through a power cycle, you must save
the script to nonvolatile memory.
To save a script to nonvolatile memory:
1. Create and load a script (see Working with scripts (on page 13-5
)).
2. Send the command scriptVar.save(), where scriptVar is the name of the script.
Example: Save a user script to nonvolatile memory
Assume a script named test1 has been loaded. test1 is saved into
nonvolatile memory.
