High Voltage SourceMeter Instrument Reference Manual Section 13:
Introduction to TSP commands
2470-901-01 Rev. A / May 2019 13-9
Saving a script to a USB flash drive
You can save scripts to a USB flash drive.
To save a script to an external USB flash drive:
1. Load a script.
2. Insert a USB flash drive into the USB port on the front panel.
3. Send the command scriptVar.save("/usb1/filename.tsp"), where scriptVar is the
v
ariable referencing the script and filename is the name of the file.
Rename a script
To rename a script in the runtime environment:
1. Load the script into the runtime environment with a different name.
2. Delete the previous version of the script.
To rename a script in nonvolatile memory:
Send the commands:
scriptVar = script.load(file)
scriptVar.save()
Where:
scriptVar is the name of variable that references the script
file is the path and file name of the script file to load
For example, to load a script named test8 from the USB flash drive and save it to nonvolatil
e
memory, send the commands:
test8 = script.load("/usb1/test8.tsp")
test8.save()
If the new name is the same as a name that is already used for a script, an event message is
displayed and the script is not saved.
