CHAPTER57 Reporting Information to External Party
Mediant 1000 Gateway & E-SBC | User's Manual
Configuring CDR Filters and Report Level
You can configure various CDR filters and the stage of the call at which you want the device to
generate and send CDRs. For a detailed description of the parameters described in this section,
see Syslog, CDR and Debug Parameters.
➢ To configure CDR filters and report level:
1. Open the Call Detail Record Settings page (Troubleshoot menu > Troubleshoot tab > Call
Detail Record folder > Call Detail Record Settings).
2. Configure CDR filters:
● In the 'Call-End CDR SIP Reasons Filter' [CallEndCDRSIPReasonsFilter] field, configure
the SIP release cause codes that if received for calls, the device does not generate and
send Call-End CDRs.
● From the 'Call-End CDR Zero Duration Filter' [CallEndCDRZeroDurationFilter] drop-down
list, select Enable if you want the device to not generate and send Call-End CDRs for
calls of zero (0) duration.
3. Configure the call stage at which CDRs are generated and sent:
● From the 'CDR Report Level' [CDRReportLevel] drop-down list, select the stage of the
call at which you want signaling-related CDRs to be generated and sent.
● (SBC Application Only) From the 'Media CDR Report Level' [MediaCDRReportLevel]
drop-down list, select the stage of the call at which you want media-related CDRs to be
generated and sent.
4. Click Apply.
Configuring CDR Reporting to REST Server
You can configure the device to send signaling-related CDRs to a REST server using AudioCodes
REST API. The CDRs are sent in JSON format.
You can customize the CDRs that are sent to the REST server, by adding CDR fields
or changing their names. For more information, see Customizing CDRs for SBC Calls
and Test Calls on page1020 for SBC calls and Customizing CDRs for Gateway Calls
on page1015 for Gateway calls.
➢ To configure CDR reporting to a REST server:
1. Enable the Syslog feature for sending log messages (CDRs) generated by the device to a
collecting log message server. For more information, see Enabling Syslog.
2. Configure the REST server:
- 975 -
