CHAPTER13 Network
Mediant 1000 Gateway & E-SBC | User's Manual
Configuring the Internal SRV Table
The Internal SRV table lets you configure up to 10 SRV rows. The table is used to resolve
hostnames into DNS A-Records. You can assign three different A-Records per hostname, where
each A-Record includes the hostname, priority, weight, and port.
The device first attempts to resolve a domain name using this table. If the domain name is not
configured in this table, the device performs an SRV resolution using an external DNS server
whose address is configured for the associated IP network interface in the IP Interfaces table. If the
IP network interface is not configured with a DNS address, the device performs an SRV resolution
with the default external DNS server (see Configuring Default DNS Servers on page117).
The following procedure describes how to configure the Internal SRV table through the Web
interface. You can also configure it through ini file [SRV2IP] or CLI (configure network >
dns srv2ip).
➢ To configure the device's SRV table:
1. Open the Internal SRV table (Setup menu > IP Network tab > DNS folder > Internal SRV).
2. Click New; the following dialog box appears:
3. Configure an SRV rule according to the parameters described in the table below.
4. Click Apply, and then save your settings to flash memory.
Table 13-12:Internal SRV Table Parameter Descriptions
Parameter Description
General
'Index' Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
'Domain Name'
domain-name
[Srv2Ip_
InternalDomain]
Defines the hostname to be translated.
The valid value is a string of up to 31 characters. By default, no value is
defined.
- 120 -
