CHAPTER54 Viewing VoIP Status
Mediant 1000 Gateway & E-SBC | User's Manual
Column Name Description
■ The parameter is applicable only if the parameter 'Alt Routing Tel to
IP Mode' is set to 'QoS' or 'Both' (AltRoutingTel2IPMode = 2 or 3).
■ The parameter is reset if two minutes elapse without a call to the
destination.
DNS Status DNS status:
■ "DNS Disable"
■ "DNS Resolved"
■ "DNS Unresolved"
Viewing Gateway CDR History
You can view historical Call Detail Records (CDR) of Gateway calls in the Gateway CDR History
table. The table displays the last 4,096 CDRs. CDR history information is stored on the device’s
memory. When a new CDR is generated, the device adds it to the top of the table and all existing
entries are shifted one down in the table. If the table has reached maximum capacity of entries and
a new CDR is added, the last CDR entry is removed from the table.
● The CDR fields in the table cannot be customized.
● If the device is reset, all CDRs are deleted from memory and from the table.
➢ To view Gateway CDR history:
■ Web: Open the Gateway CDR History table (Monitor menu > Monitor tab > VoIP Status
folder > Gateway CDR History).
■ CLI:
● All CDR history:
# show voip calls history gw
● CDR history for a specific SIP session ID:
# show voip calls history gw <session ID>
Table 54-6: Gateway CDR History Table
Field Description
Call End Time Displays the time at which the call ended. The time is displayed in the
format, hh:mm:ss, where hh is the hour, mm the minutes and ss the
seconds (e.g., 15:06:36).
End Point Displays the device's endpoint involved in the call, displayed in the format:
- 957 -
