AudioCodes E-SBC User Manual

CHAPTER68 Configuration Parameters Reference
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
configure voip > sip-
definition settings >
enable-call-transfer-
using-reinvites
[EnableCallTransferUsingReinvites]
■ [0] Disable = (Default) Call transfer is done using
REFER messages.
■ [1] Enable = Call transfer is done by sending re-
INVITE messages (instead of REFER).
Note:
■ To support the feature, the device must be
installed with an MPM.
■ The device uses two DSP channels per transferred
call. Thus, to use this feature, you also need to
configure the maximum number of available DSP
channels, using the MediaChannels parameter.
■ The parameter is applicable only to FXS
interfaces.
Three-Way Conferencing Parameters
The three-way conferencing parameters are described in the table below.
Table 68-45:Three-Way Conferencing Parameters
Parameter Description
'Enable 3-Way Conference'
configure voip > gateway
dtmf-supp-service supp-
service-settings >
enable-3w-conf
[Enable3WayConference]
Enables the 3-Way Conference feature.
■ [0] Disable (default)
■ [1] Enable
Note: For the parameter to take effect, a device reset is
required.
'3-Way Conference Mode'
configure voip > gateway
dtmf-supp-service supp-
service-settings > 3w-
conf-mode
[3WayConferenceMode]
Defines the mode of operation for three-way
conferencing.
■ [0] AudioCodes Media Server = (Default) The
conference-initiating INVITE sent by the device, uses
the ConferenceID concatenated with a unique
identifier as the Request-URI. This same Request-
URI is set as the Refer-To header value in the
REFER messages that are sent to the two remote
parties. This conference mode is used when operating
with AudioCodes IPMedia conferencing server.
■ [1] Non-AudioCodes Media Server = The
conference-initiating INVITE sent by the device, uses
only the ConferenceID as the Request-URI. The
Conference server sets the Contact header of the 200
OK response to the actual unique identifier
(Conference URI) to be used by the participants. This
Conference URI is then included by the device in the
Refer-To header value in the REFER messages sent
by the device to the remote parties. The remote
parties join the conference by sending INVITE
messages to the conference using this conference
URI.
- 1251 -
