CHAPTER57 Reporting Information to External Party
Mediant 1000 Gateway & E-SBC | User's Manual
Attrib-
ute ID
Attribute
Name
Vendor-
Specific
Attribute
(VSA) ID
Description
Value
Format
Example AAA
Response Attributes
26 h323-
return-
code
103 The reason
for failing
authentication
(0 = ok, other
number failed)
Numeri
c
0 Request
accepted
Stop
Acc
44 acct-
session-id
(Standar
d)
A unique
accounting
identifier –
match start &
stop
String - Stop
Acc
Below is an example of RADIUS Accounting, where non-standard parameters are preceded with
brackets:
Accounting-Request (4)
user-name = 111
acct-session-id = 1
nas-ip-address = 212.179.22.213
nas-port-type = 0
acct-status-type = 2
acct-input-octets = 4841
acct-output-octets = 8800
acct-session-time = 1
acct-input-packets = 122
acct-output-packets = 220
called-station-id = 201
calling-station-id = 202
// Accounting non-standard parameters:
(4923 33) h323-gw-id =
(4923 23) h323-remote-address = 212.179.22.214
(4923 1) h323-ivr-out = h323-incoming-conf-id:02102944 600a1899 3fd61009 0e2f3cc5
(4923 30) h323-disconnect-cause = 22 (0x16)
(4923 27) h323-call-type = VOIP
(4923 26) h323-call-origin = Originate
(4923 24) h323-conf-id = 02102944 600a1899 3fd61009 0e2f3cc5
Querying Device Channel Resources using SIP
OPTIONS
The device reports its maximum and available channel resources in SIP 200 OK responses upon
receipt of SIP OPTIONS messages. The device sends this information in the SIP X-Resources
header with the following parameters:
■ telchs: Specifies the total telephone channels and the number of free (available) telephone
channels.
- 1031 -
