CHAPTER20 SIP Definitions
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
'Username'
[GWUserInfoTable_Username]
Defines the username for registering the user when
authentication is necessary.
The valid value is a string of up to 60 characters. By
default, no value is defined.
'Password'
[GWUserInfoTable_Password]
Defines the password for registering the user when
authentication is necessary.
The valid value is a string of up to 20 characters.
'Status' (Read-only field) Displays the status of the user:
â– "Registered"
â– "Not Registered"
Configuring Gateway User Information Table through CLI
The User Information table can be configured through CLI using the following commands:
â– To add and/or modify a user (example):
# configure voip
(config-voip)# sip-definition proxy-and-registration
(sip-def-proxy-and-reg)# user-info gw-user-info <index, e.g., 1>
(gw-user-info-1)# username JohnDee
(
gw-u
ser
-
in
f
o-
1
)
#
<act
iv
a
t
e
|
e
x
it
>
â– To delete a specific user, use the no command:
# configure voip
(config-voip)# sip-definition proxy-and-registration
(sip-def-proxy-and-reg)# no user-info gw-user-info <index, e.g., 1>
â– To import users from a file:
# configure voip
(config-voip)# sip-definition proxy-and-registration
(sip-def-proxy-and-reg)# user-info gw-user-info import-csv-from <URL>
â– To export users to a .csv file:
# configure voip
(config-voip)# sip-definition proxy-and-registration
(sip-def-proxy-and-reg)# user-info gw-user-info export-csv-to <URL>
â– To view all table entries:
(sip-def-proxy-and-reg)# user-info gw-user-info display
---- gw-user-info-0 ----
pbx-ext (405)
global-phone-num (405)
display-name (Ext405)
username (user405)
- 475 -
