CHAPTER16 Services
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
The valid value to enable this feature is any value
greater than 0. The default is 0 (i.e., if there is no activity
on the connection, the device does not send "abandon"
requests and the LDAP server may disconnect).
Note: The parameter is applicable only to LDAP
connections that are used for routing (i.e., the 'Type'
parameter is configured to Control).
Configuring LDAP DNs (Base Paths) per LDAP Server
The LDAP Search DN table lets you configure LDAP base paths. The table is a "child" of the LDAP
Servers table (see Configuring LDAP Servers) and configuration is done per LDAP server. For the
device to run a search using the LDAP service, the base path to the directory’s subtree, referred to
as the distinguished name object (or DN), where the search is to be done must be configured. For
each LDAP server, you can configure up to three base paths.
The following procedure describes how to configure DNs per LDAP server through the Web
interface. You can also configure it through ini file [LdapServersSearchDNs] or CLI (configure
system > ldap ldap-servers-search-dns).
➢ To configure an LDAP base path per LDAP server:
1. Open the LDAP Servers table (Setup menu > IP Network tab > RADIUS & LDAP folder >
LDAP Servers).
2. In the table, select the row of the LDAP server for which you want to configure DN base paths,
and then click the LDAP Servers Search Based DNs link located below the table; the LDAP
Server Search Base DN table opens.
3. Click New; the following dialog box appears:
4. Configure an LDAP DN base path according to the parameters described in the table below.
5. Click Apply, and then save your settings to flash memory.
Table 16-9: LDAP Server Search Base DN Table Parameter Descriptions
Parameter Description
'Index'
set internal-index
[LdapServersSearchDNs_
Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
- 219 -
