CHAPTER65 Testing SIP Signaling Calls
Mediant 1000 Gateway & E-SBC | User's Manual
Statistics Field Description
■ "Running (Calls: <number of active calls>, ASR: <ASR>%)": Test
call has been started (i.e., the Dial command was clicked) and shows
the following:
✔ Number of currently active test calls.
✔ Number of successfully answered calls out of the total number of
calls attempted (Answer Success Ratio or ASR).
■ "Receiving (<number of active calls>)": Test call has been
automatically activated by calls received for this configured test call
endpoint from the configured remote endpoint. When all these calls
terminate, the status returns to "Idle".
■ "Terminating (<number of active calls>)": The Drop Call command
has been clicked to stop the test call and the test call is in the process
of terminating the currently active test calls.
■ "Done - Established Calls: <number of established calls>, ASR:
<ASR>%": Test call has been successfully completed (or was
prematurely stopped by clicking the Drop Call command) and shows
the following:
✔ Total number of test calls that were established.
✔ Number of successfully answered calls out of the total number of
calls attempted (ASR).
MOS Status MOS count and color threshold status of local and remote sides according
to the assigned QoE Profile.
Delay Status Packet delay count and color-threshold status of local and remote sides
according to the assigned QoE Profile.
Jitter Status Jitter count and color-threshold status of local and remote sides according
to the assigned QoE Profile.
Packet Loss
Status
Packet loss count and color-threshold status of local and remote sides
according to the assigned QoE Profile.
Bandwidth
Status
Tx/Rx bandwidth and color-threshold status according to the assigned
Bandwidth Profile.
Configuring DTMF Tones for Test Calls
By default, the device plays the DTMF signal tone "3212333" to remote tested endpoints for
answered calls (incoming and outgoing). For basic test calls (as described in Configuring Basic
Test Calls), the device can play only the configured DTMF tones (or none, if not configured). For
test call endpoints that are configured in the Test Call Rules table, you can configure the device to
play either DTMF tones or a tone from an installed PRT file (Test Call Tone). For more information,
see Configuring Test Call Endpoints.
● You can configure the DTMF signaling type (e.g., out-of-band or in-band) using the
'DTMF Transport Type' [DTMFTransportType] parameter.
● To generate DTMF tones, the device's DSP resources are required.
- 1079 -
