CHAPTER48 SBC Configuration Wizard
Mediant 1000 Gateway & E-SBC | User's Manual
This page is applicable only to IP PBXs that support such configuration.
➢ To configure remote users:
1. Select the 'Enable remote users' check box.
2. Under the SIP Interface group, configure the SIP interface for the remote users:
● 'Transport Type': Configure the SIP transport type.
● 'Listening Port': Configure the SIP port used by the device for communicating with remote
users. For One Port: LAN and One Port: WAN network topologies, you must configure
different listening ports for communication with the IP PBX and remote users.
3. Under the Media Ports (Realm) group, configure the media protocol type and ports used by the
device for communicating with the remote users:
● 'Media Protocol': Configure the media protocol type (RTP or SRTP).
● 'Base Port': Configure the first media port.
● 'Number Of Sessions': Configure the number of required media sessions. For more
information on media port ranges and number of sessions, see Configuring RTP Base
UDP Port.
4. Click Next; the Summary page appears (see Summary Page).
Summary Page
The Summary wizard page displays a summary of your configuration.
- 917 -
