CHAPTER29 Analog Gateway
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
'Auto Dial Status'
auto-dial-status
[TargetOfChannel_
Type]
Enables automatic dialing.
■ [0] Disable = Automatic dialing for the specific port is disabled.
■ [1] Enable = (Default) Automatic dialing is enabled and the phone
number configured in the 'Destination Phone Number' field is
automatically dialed if the following occurs:
✔ FXS interfaces: The phone is off-hooked
✔ FXO interfaces: A ring signal (from a PBX/PSTN switch) is
detected on the FXO line. The device initiates a call to the
destination without seizing the FXO line. The line is seized
only after the SIP call is answered.
■ [2] Hotline = Automatic dialing is done after an interval
configured by the 'Hotline Dial Tone Duration' parameter:
✔ FXS interfaces: When the phone is off-hooked and no digit is
dialed within a user-defined time, the configured destination
number is automatically dialed.
✔ FXO interfaces: If a ring signal is detected, the device seizes
the FXO line, plays a dial tone, and then waits for DTMF
digits. If no digits are detected within a user-defined time, the
configured destination number is automatically dialed by
sending a SIP INVITE message with this number.
'Hotline Dial Tone
Duration'
hotline-dia-
ltone-duration
[TargetOfChannel_
HotLineToneDuration]
Defines the duration (in seconds) after which the destination phone
number is automatically dialed. This is applicable only if the port has
been configured for Hotline (i.e., 'Auto Dial Status' is set to Hotline).
The valid value is 0 to 60. The default is 16.
Note: You can configure this Hotline interval for all ports, using the
global parameter, HotLineToneDuration.
Configuring Caller Display Information
The Caller Display Information table lets you configure caller identification strings (Caller ID) per
analog port. The table also lets you enable the device to send Caller ID to the IP side for Tel-to-IP
calls. The device sends the configured caller ID in the From header of the outgoing SIP INVITE
message. For more information on Caller ID restriction according to destination/source prefixes,
see Configuring Source/Destination Number Manipulation.
● The feature is applicable to FXS and FXO interfaces.
● If an FXS port receives 'private' or 'anonymous' strings in the SIP From header, the
calling name or number is not sent to the Caller ID display.
● If the device detects Caller ID on an FXO line (EnableCallerID = 1), it uses this
Caller ID instead of the Caller ID configured in the Caller Display Information table.
The following procedure describes how to configure caller ID through the Web interface. You can
also configure it through ini file [CallerDisplayInfo] or CLI (configure voip > gateway
analog caller-display-info).
- 698 -
