CHAPTER50 System Status
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
Device Up Time Duration that the device has been up and running since the last reset
(uptime). The duration is displayed in the following format:
dd:hh:mm:ss.ss.
For example, "1d:21h:40m:21s:75.22" means that the device has been
running for one day and 21 hours, 40 minutes and 21.22 seconds.
Device
Administrative
State
Administrative status ("Unlocked" or "Locked"), as performed in Locking
and Unlocking the Device.
Device
Operational State
Operational status:
■ "Disabled"
■ "Enabled"
■ "Error"
■ "Unknown"
Flash Size
[Mbytes]
Size of the non-volatile storage memory (flash), measured in megabytes.
RAM Size
[Mbytes]
Size of the random access memory (RAM), measured in megabytes.
CPU Speed
[MHz]
Clock speed of the CPU, measured in megahertz (MHz).
Versions
Version ID Software version number.
DSP Type Type of DSP.
DSP Software
Version
DSP software version.
DSP Software
Name
DSP software name.
Flash Version Flash memory version number.
Loaded Files: Displays installed Auxiliary files. You can also delete a file, by clicking the
corresponding Delete button, as described in Deleting Auxiliary Files.
Viewing Device Status on Monitor Page
The Web interface's Monitor page provides basic status and information on the device. The page is
useful in that it allows you to easily obtain an overview of the device's operating status at a glance.
➢ To view device status and information on the Monitor home page:
■ On the Menu bar, click Monitor or if you are already in the Monitor menu's Navigation tree,
click Monitor.
The Monitor page displays the following groups of information:
■ Device Information:
- 924 -
