CHAPTER44 Loading Auxiliary Files
Mediant 1000 Gateway & E-SBC | User's Manual
First Signal On Time [10msec]=300; the dial tone is detected after 3 sec
First Signal Off Time [10msec]=0
Second Signal On Time [10msec]=0
Second Signal Off Time [10msec]=0
Distinctive Ringing
Distinctive Ringing is applicable only to FXS interfaces. Using the Distinctive Ringing section of
the Call Progress Tones Auxiliary file, you can create up to 16 Distinctive Ringing patterns. Each
ringing pattern configures the ringing tone frequency and up to four ringing cadences. The same
ringing frequency is used for all the ringing pattern cadences. The ringing frequency can be
configured in the range of 10 to 200 Hz with a 5 Hz resolution.
The feature is applicable only to FXS interfaces.
Each of the ringing pattern cadences is specified by the following parameters:
■ Burst Ring On Time: Configures the cadence to be a burst cadence in the entire ringing
pattern. The burst relates to On time and the Off time of the same cadence. It must appear
between 'First/Second/Third/Fourth' string and the 'Ring On/Off Time' This cadence rings once
during the ringing pattern. Otherwise, the cadence is interpreted as cyclic: it repeats for every
ringing cycle.
■ Ring On Time: Specifies the duration of the ringing signal.
■ Ring Off Time: Specifies the silence period of the cadence.
The Distinctive Ringing section of the ini file format contains the following strings:
■ [NUMBER OF DISTINCTIVE RINGING PATTERNS]: Contains the following key:
● 'Number of Distinctive Ringing Patterns' defining the number of Distinctive Ringing
signals that are defined in the file.
■ [Ringing Pattern #X]: Contains the Xth ringing pattern definition (starting from 0 and not
exceeding the number of Distinctive Ringing patterns defined in the first section minus 1) using
the following keys:
● Ring Type: Must be equal to the Ringing Pattern number.
● Freq [Hz]: Frequency in hertz of the ringing tone.
● First (Burst) Ring On Time [10 msec]: 'Ring On' period (in 10 msec units) for the first
cadence on-off cycle.
● First (Burst) Ring Off Time [10 msec]: 'Ring Off' period (in 10 msec units) for the first
cadence on-off cycle.
● Second (Burst) Ring On Time [10 msec]: 'Ring On' period (in 10 msec units) for the
second cadence on-off cycle.
● Second (Burst) Ring Off Time [10 msec]: 'Ring Off' period (in 10 msec units) for the
second cadence on-off cycle.
● Third (Burst) Ring On Time [10 msec]: 'Ring On' period (in 10 msec units) for the third
cadence on-off cycle.
● Third (Burst) Ring Off Time [10 msec]: 'Ring Off' period (in 10 msec units) for the third
cadence on-off cycle.
● Fourth (Burst) Ring On Time [10 msec]: 'Ring Off' period (in 10 msec units) for the
fourth cadence on-off cycle.
● Fourth (Burst) Ring Off Time [10 msec]: 'Ring Off' period (in 10 msec units) for the
fourth cadence on-off cycle.
- 865 -
