CHAPTER29 Analog Gateway
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
destination
[FwdInfo_
Destination]
Note: If the parameter is configured with only a telephone number and a
Proxy isn't used, this forwarded-to phone number must be specified in the
Tel-to-IP Routing table (see Configuring Tel-to-IP Routing Rules).
'No Reply Time'
no-reply-
time
[FwdInfo_
NoReplyTime]
If you have set the 'Type' parameter for this port to No Answer or On Busy
or No Answer, then configure the number of seconds the device waits
before forwarding the call to the specified phone number.
Configuring Caller ID Permissions
The Caller ID Permissions table lets you enable Caller ID generation per port for FXS interfaces
and detection for FXO interfaces.
● The feature is applicable only to FXS and FXO interfaces.
● For ports that are not configured in the table, Caller ID is according to the global
parameter, as described in Enabling Caller ID Generation and Detection on Tel
Side.
The following procedure describes how to configure Caller ID permissions through the Web
interface. You can also configure it through ini file [EnableCallerID] or CLI (configure voip >
gateway analog enable-caller-id).
➢ To configure Caller ID permissions per port:
1. Open the Caller ID Permissions table (Setup menu > Signaling & Media tab > Gateway
folder > Analog Gateway > Caller ID Permissions).
2. Select the row corresponding to the port that you want to configure, and then click Edit; the
following dialog box appears:
3. Configure a Caller ID permission per port according to the parameters described in the table
below.
4. Click Apply.
- 702 -
