CHAPTER34 Routing SBC
Mediant 1000 Gateway & E-SBC | User's Manual
General
'Request Type' Dial Plan
'Request Target' ITSP
'Request Key' Param.Call.Src.User
'Condition ' DialPlan.Found exists
Action
'Action Subject' SrcTags
'Action Type' Modify
'Action Value' DialPlan.Result
3. Open the SIP Interfaces table (see Configuring SIP Interfaces on page331), and then
configure a SIP Interface with the 'Call Setup Rules Set ID' parameter set to the 'Rules Set ID'
value of your Call Setup Rules. In our example, the SIP Interface is named "SIPIfx-Tags" and
the parameter is configured to 1.
4. Open the Classification table, and then configure a rule with the following:
Match
'Source SIP
Interface'
SIPIfx-Tags (or select Any)
Action
'IP Group
Selection'
Tagged IP Group
'IP Group Tag
Name'
Country
Note: Enter the tag's name only. If the tag only has a value, then enter
"default".
5. Open the IP Groups table (see Configuring IP Groups on page344), and then configure IP
Groups with the 'Tags' parameter set to the appropriate tag. If the source tag has a name and
value, then configure the parameter as name=value (e.g., "Country=Ireland"). If it only has a
value, then configure it with the value. In our example, the following IP Groups are configured:
Name Tags
IPGroup-1 Country=Ireland
IPGroup-2 Country=Scotland
IPGroup-3 Country=England
Configuring SBC IP-to-IP Routing
The IP-to-IP Routing table lets you configure up to 615 SBC IP-to-IP routing rules.
Configuration of IP-to-IP routing rules includes two areas:
■ Match: Defines the characteristics of the incoming SIP dialog message (e.g., IP Group from
which the message is received).
- 771 -
