CHAPTER68 Configuration Parameters Reference
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
â– [3] End Call & End Segment = RTCP XR is
sent at the end of the call and at the end of each
media segment of the call. A media segment is a
change in media, for example, when the coder is
changed or when the caller toggles between two
called parties (using call hold/retrieve). The RTCP
XR sent at the end of a media segment contains
information only of that segment. If the segment
does not contain RTP/RTCP content, the RTCP
XR is not sent. For call hold, the device sends an
RTCP XR each time the call is placed on hold and
each time it is retrieved. In addition, the Start
timestamp in the RTCP XR indicates the start of
the media segment; the End timestamp indicates
the time of the last sent periodic RTCP XR
(typically, up to 5 seconds before reported
segment ends).
Note: The parameter is applicable only to the
Gateway application.
'Publication IP Group ID'
publication-ip-group-id
[PublicationIPGroupID]
Defines the IP Group to where the device sends
RTCP XR reports.
By default, no value is defined.
'SBC RTCP XR Report Mode'
configure voip > sip-
definition settings > sbc-
rtcpxr-report-mode
[SBCRtcpXrReportMode]
Enables the sending of RTCP XR reports of QoE
metrics at the end of each call session (i.e., after a
SIP BYE). The RTCP XR is sent in the SIP
PUBLISH message.
â– [0] Disable (default)
â– [1] End of Call
Note: The parameter is applicable only to the SBC
application.
Gateway Application Parameters
this section describes the parameters of the Gateway application.
Fax and Modem Parameters
The fax and modem parameters are described in the table below.
Table 68-35:Fax and Modem Parameters
Parameter Description
'Fax Transport Mode'
configure voip > media fax-modem >
fax-transport-mode
[FaxTransportMode]
Determines the fax transport mode used
by the device.
â– [0] Disable = transparent mode
â– [1] T.38 Relay (default)
â– [2] Bypass
- 1211 -
