CHAPTER16 Services
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
■ [0] Sequential = (Default) The query is done in each DN
object, one by one, until a result is returned. For example,
a search for the DN object record "JohnD" is first run in
DN object "Marketing" and if a result is not found, it
searches in "Sales", and if not found, it searches in
"Administration", and so on.
■ [1] Parallel = The query is done in all DN objects at the
same time. For example, a search for the DN object
record "JohnD" is done at the same time in the
"Marketing", "Sales" and "Administration" DN objects.
Cache
'Cache Entry Timeout'
cache-entry-timeout
[LdapServersGroups_
CacheEntryTimeout]
Defines the duration (in minutes) that an entry in the device's
LDAP cache is valid. If the timeout expires, the cached entry
is used only if there is no connectivity with the LDAP server.
The valid range is 0 to 35791. The default is 1200. If set to 0,
the LDAP entry is always valid.
'Cache Entry Removal
Timeout'
cache-entry-removal-
timeout
[LdapServerGroups_
CacheEntryRemovalTimeout]
Defines the duration (in hours) after which the LDAP entry is
deleted from the device's LDAP cache.
The valid range is 0 to 596. The default is 0 (i.e., the entry is
never deleted).
Configuring LDAP Servers
The LDAP Servers table lets you configure up to 82 LDAP servers. The table defines the address
and connectivity settings of the LDAP server. The LDAP server can be configured for SIP-related
queries (e.g., routing and manipulation) or LDAP-based management user login authentication and
authorization (username-password).
The following procedure describes how to configure an LDAP server through the Web interface.
You can also configure it through ini file [LdapConfiguration] or CLI (configure system >
ldap ldap-configuration).
When you configure an LDAP server, you need to assign it an LDAP Server Group.
Therefore, before you can configure an LDAP server in the table, you must first
configure at least one LDAP Server Group in the LDAP Server Groups table (see
Configuring LDAP Server Groups).
➢ To configure an LDAP server:
1. Open the LDAP Servers table (Setup menu > IP Network tab > RADIUS & LDAP folder >
LDAP Servers).
2. Click New; the following dialog box appears:
- 214 -
