CHAPTER13 Network
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
'Name'
port
[PhysicalPortsTable_
Port]
(Read-only) Displays the Ethernet port number. See the figure in the
beginning of this section for the mapping between the GUI port
number and the physical port on the chassis.
'Description'
port-
description
[PhysicalPortsTable_
PortDescription]
Defines a description of the port.
By default, the value is "User Port #<row index>".
Note: Each row must be configured with a unique name.
'Mode'
mode
[PhysicalPortsTable_
Mode]
(Read-only) Displays the mode of the port.
■ [0] Disable
■ [1] Enable (default)
'Speed and Duplex'
speed-duplex
[PhysicalPortsTable_
SpeedDuplex]
Defines the speed and duplex mode of the port.
■ [0] 10BaseT Half Duplex
■ [1] 10BaseT Full Duplex
■ [2] 100BaseT Half Duplex
■ [3] 100BaseT Full Duplex
■ [4] Auto Negotiation (default)
■ [6] 1000BaseT Half Duplex
■ [7] 1000BaseT Full Duplex
Ethernet Group
'Member of Ethernet
Group'
group-member
[PhysicalPortsTable_
GroupMember]
(Read-only) Displays the Ethernet Group to which the port belongs.
To assign the port to a different Ethernet Group, see Configuring
Ethernet Port Groups.
'Group Status'
group-status
[PhysicalPortsTable_
GroupStatus]
(Read-only) Displays the status of the port:
■ "Active": Active port. When the Ethernet Group includes two ports
and their transmit/receive mode is configured to 2RX 1TX or 2RX
2TX, both ports show "Active".
Configuring Ethernet Port Groups
The Ethernet Groups table lets you configure Ethernet Groups. An Ethernet Group represents a
physical Ethernet port(s) on the device. You can assign an Ethernet Group with one, two, or no
ports (members). When two ports are assigned to an Ethernet Group, 1+1 Ethernet port redundancy
can be implemented in your network.In such a configuration, one port can be active while the other
standby or both ports can be active, depending on the ports' transmit (Tx) and receive (Rx) settings.
This provides port redundancy within the Ethernet Group, whereby if a port is disconnected the
device switches over to the other port in the Ethernet Group. If you configure an Ethernet Group
with only one port, the Ethernet Group operates as a single port (no redundancy).
