CHAPTER20 SIP Definitions
Mediant 1000 Gateway & E-SBC | User's Manual
■ Export the configured users to a .csv file: From the Action drop-down list, choose Export and
save the file to a folder on your computer.
■ Register and un-register users:
● To register a user, select the user, and then from the Action drop-down list, choose
Register.
● To un-register a user, select the user, and then from the Action drop-down list, choose
Un-Register.
To configure the User Information table, make sure that you have enabled the feature
(see Enabling the User Info Table).
The following procedure describes how to configure and register users in the User Information table
through the Web interface.
➢ To configure the User Information table through the Web interface:
1. Open the User Information table (Setup menu > Signaling & Media tab > Gateway folder >
User Information).
2. Click New; the following dialog box appears:
3. Configure a user according to the table below.
4. Click Apply.
Table 20-2: User Information Table Parameter Descriptions
Parameter Description
'Index'
[GWUserInfoTable_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
'PBX Extension'
[GWUserInfoTable_
PBXExtension]
Defines the PBX extension number.
The valid value is a string of up to 10 characters.
Note: The parameter is mandatory.
'Global Phone Number'
[GWUserInfoTable_
GlobalPhoneNumber]
Defines the "global" phone number for the IP side.
The valid value is a string of up to 20 characters.
Note: The parameter is mandatory.
'Display Name'
[GWUserInfoTable_
DisplayName]
Defines the Caller ID of the PBX extension.
The valid value is a string of up to 30 characters.
- 474 -
