CHAPTER8 SNMP-Based Management
Mediant 1000 Gateway & E-SBC | User's Manual
2. Configure the SNMP trap manager according to the table below.
3. Select the check boxes corresponding to the configured SNMP managers that you want to
enable.
4. Click Apply.
● Rows whose corresponding check boxes are cleared revert to default settings
when you click Apply.
● To enable the sending of the trap event, acPer-
formanceMonitoringThresholdCrossing, which is sent whenever a threshold (high
or low) of a performance monitored SNMP MIB object is crossed, configure the ini
file parameter [PM_EnableThresholdAlarms] to [1]. Once enabled, you can change
its default low and high threshold values. For more information, see the SNMP
Reference Guide for Gateways-SBCs-MSBRs.
● Instead of configuring SNMP trap managers with an IP address in dotted-decimal
notation, you can configure a single SNMP trap manager with an FQDN (see
Configuring an SNMP Trap Destination with FQDN.
Table 8-2: SNMP Trap Destinations Table Parameters Description
Parameter Description
(check box)
[SNMPManagerIsUsed_x]
Enables the SNMP manager to receive traps and
checks the validity of the configured destination (IP
address and port number).
■ [0] (check box cleared) = (Default) Disables
SNMP manager
■ [1] (check box selected) = Enables SNMP
manager
'IP Address'
[SNMPManagerTableIP_x]
Defines the IP address (in dotted-decimal notation,
e.g., 108.10.1.255) of the remote host used as the
SNMP manager. The device sends SNMP traps to
this IP address.
'Trap Port'
[SNMPManagerTrapPort_x]
Defines the port number of the remote SNMP
manager. The device sends SNMP traps to this port.
The valid value range is 100 to 4000. The default is
162.
'Trap User'
[SNMPManagerTrapUser]
Associates a trap user with the trap destination. This
determines the trap format, authentication level, and
encryption level.
■ v2cParams (default) = SNMPv2 user community
string
■ SNMPv3 user configured in Configuring SNMP
V3 Users
- 66 -
