CHAPTER57 Reporting Information to External Party
Mediant 1000 Gateway & E-SBC | User's Manual
➢ To customize SBC and Test Call CDRs:
1. Open the SBC CDR Format table (Troubleshoot menu > Troubleshoot tab > Call Detail
Record folder > SBC CDR Format).
2. Click New; the following dialog box appears:
3. Configure the CDR according to the parameters described in the table below.
4. Click Apply.
Examples of configured CDR customization rules are shown below:
Table 57-4: SBC CDR Format Table Parameter Descriptions
Parameter Description
'Index'
[SBCCDRFormat_
Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
'CDR Type'
cdr-type
[SBCCDRFormat_
CDRType]
Defines the application type for which you want to customize CDRs.
â– [1] Syslog SBC = (Default) Customizes CDR fields for SIP
signaling-related CDRs sent in Syslog messages.
â– [3] Syslog Media = Customizes CDR fields for media-related CDRs
sent in Syslog messages.
â– [5] Local Storage SBC = Customizes CDR fields that are stored
locally on the device. Only signaling-related CDRs are stored locally
on the device.
â– [7] RADIUS SBC = Customizes CDR fields (i.e., RADIUS
Attributes) for CDRs sent in RADIUS accounting request
messages.
â– [11] JSON SBC = Customizes CDR fields for SIP signaling-related
CDRs that are sent in JSON format to the REST server using the
device's REST API.
- 1021 -
