Parameter Description
■ [1] = Enable
Note:
■ When the device is installed with an MPM, the
parameter is enabled by default.
■ For the parameter to take effect, a device reset is
required.
[IPmediaChannels] This table ini file parameter defines the number of DSP
channels that are "borrowed" from each of the device's
digital modules for IP media feature. The format of the
ini file table parameter is as follows:
[IPMediaChannels ]
FORMAT IPMediaChannels_Index =
IPMediaChannels_ModuleID, IPMediaChannels_
DSPChannelsReserved;
[\IPMediaChannels ]
For example, the below settings use 15 and 10 DSP
channels from modules 1 and 2, respectively:
IPMediaChannels 1 = 1, 15;
IPMediaChannels 2 = 2, 10;
Note:
■ The value of DSPChannelsReserved must be in
multiples of 5 (since the reservation is done per
DSP device and not per DSP channel).
■ By default, the MPM is set to the maximum value
of IPM channels, therefore, there is no need to
define it.
■ By default, a digital module (i.e., TRUNKS module)
is set to 0 IPM channels.
■ For DSP utilization options, see DSP Channel
Resources.
Conferencing Parameters
'Conference ID'
configure voip > gateway
dtmf-supp-service supp-
service-settings > conf-id
[ConferenceID]
Defines the Conference Identification string.
The valid value is a string of up to 16 characters. The
default is "conf".
Note: To join a conference, the INVITE URI must
include the Conference ID string preceded by the
number of the participants in the conference and
terminated by a unique number. For example:
INVITE sip:4conf1234@10.1.10.10
INVITE messages with the same URI join the same
conference.
Automatic Gain Control (AGC) Parameters
'Enable AGC'
configure voip > media
ipmedia > agc-enable
Global parameter enabling the AGC feature.
