CHAPTER19 Coders and Profiles
Mediant 1000 Gateway & E-SBC | User's Manual
3. Configure an IP Profile according to the parameters described in the table below.
4. Click Apply.
Table 19-5: IP Profiles Table Parameter Descriptions
Parameter Description
General
'Index'
[IpProfile_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
'Name'
profile-name
[IpProfile_ProfileName]
Defines a descriptive name, which is used when
associating the row in other tables.
The valid value is a string of up to 40 characters.
Note: The parameter value cannot contain a forward slash
(/).
'Created By Routing Server'
[IpProfile_
CreatedByRoutingServer]
(Read-only) Indicates whether the IP Profile was created
by a third-party routing server:
■ [0] No
■ [1] Yes
For more information on the third-party routing server
feature, see Centralized Third-Party Routing Server.
Media Security
'SBC Media Security Mode'
sbc-media-security-
behaviour
[IpProfile_
SBCMediaSecurityBehaviour]
Defines the handling of RTP and SRTP for the SIP entity
associated with the IP Profile.
■ [0] As is = (Default) No special handling for
RTP\SRTP is done.
■ [1] SRTP = SBC legs negotiate only SRTP media
lines, and RTP media lines are removed from the
incoming SDP offer-answer.
■ [2] RTP = SBC legs negotiate only RTP media lines,
and SRTP media lines are removed from the incoming
offer-answer.
■ [3] Both = Each offer-answer is extended (if not
already) to two media lines - one RTP and the other
SRTP.
- 396 -
