CHAPTER20 SIP Definitions
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
'Request Type'
request-type
[CallSetupRules_
QueryType]
Defines the type of query.
■ [0] None (default)
■ [1] LDAP = The Call Setup rule performs an LDAP query with an
LDAP server. To specify an LDAP server, use the 'Request Target'
parameter (see below).
■ [2] Dial Plan = The Call Setup rule performs a query with the Dial
Plan. To specify a Dial Plan, use the 'Request Target' parameter
(see below).
■ [3] ENUM = The Call Setup rule performs a query with an ENUM
(E.164 Number to URI Mapping) server for retrieving a SIP URI
address for an E.164 telephone number. The ENUM server’s
address is the address configured for the 'Primary DNS' (and
optionally, 'Secondary DNS') parameters of the IP Interface (in the
IP Interfaces table) that is specified in the ‘Request Target’
parameter (see below). For a configuration example, see Call Setup
Rule Examples on page489.
■ [4] HTTP GET = The Call Setup rule performs an HTTP GET
request (query) with an HTTP/S server. To specify an HTTP
server, use the 'Request Target' parameter (see below).
■ [5] HTTP POST Query = The Call Setup rule sends an HTTP
POST request (query) to an HTTP/S server and expects a
response from the server. To specify an HTTP server, use the
'Request Target' parameter (see below).
■ [6] HTTP POST Notification = The Call Setup rule sends an
HTTP POST request to notify an HTTP/S server of a specific
condition and does not expect a response from the server. For
example, you can configure a rule to notify the server of a 911
emergency call. To specify an HTTP server, use the 'Request
Target' parameter (see below).
'Request Target'
request-target
[CallSetupRules_
QueryTarget]
Defines one of the following, depending on the value configured for the
'Request Type' parameter (above).
■ LDAP: Defines an LDAP server (LDAP Server Group) on which to
perform an LDAP query for a defined key. To configure LDAP
Server Groups, see Configuring LDAP Server Groups.
■ Dial Plan: Defines a Dial Plan (name) in which to search for a
defined key. To configure Dial Plans, see Configuring Dial Plans.
■ ENUM: Specifies the ENUM server on which to perform the ENUM
query. The server is specified by IP Interface name (in the IP
Interfaces table). The address of the ENUM server is the address
of the 'Primary DNS' (and optionally, 'Secondary DNS') parameters
that is configured for the specified IP Interface. If you don’t specify
an IP Interface or the specified IP Interface does not exist in the IP
Interfaces table, the device uses the OAMP IP Interface.
■ HTTP GET, HTTP POST Query, and HTTP POST Notification:
Defines the HTTP server to where the device sends the HTTP
request. To configure HTTP servers, see Configuring Remote Web
Services on page243.
To configure the key, use the 'Request Key' parameter (see below).
- 485 -
