CHAPTER25 Routing
Mediant 1000 Gateway & E-SBC | User's Manual
■ Alternative Routing (when a proxy isn't used): An alternative IP destination (alternative
routing rule) can be configured for specific calls ("main" routing rule). When the "main" route
fails (e.g., busy), the device can send the call to the alternative route. You must configure the
alternative routing rules in table rows (indices) that are located anywhere below the "main"
routing rule. For example, if you configure a "main" routing rule in Index 4, the alternative
routing rule can be configured in Index 6. In addition, you must configure the alternative routing
rules with identical matching characteristics (e.g., destination prefix number) as the "main"
routing rule, but assigned with different destination IP addresses. Instead of an IP address, you
can use an FQDN to resolve into two IP addresses. For more information on alternative
routing, see Alternative Routing for Tel-to-IP Calls.
■ Advice of Charge (AOC): AOC is a pre-billing feature that tasks the rating engine with
calculating the cost of using a service (Tel-to-IP call) and relaying that information to the
customer. AOC, which is configured in the Charge Codes table, can be applied per Tel-to-IP
routing rule.
● Instead of using the table for Tel-to-IP routing, you can employ a third-party Routing
server to handle the routing decisions. For more information, see Centralized Third-
Party Routing Server.
● You can configure up to three alternative routing rules per "main" routing rule in the
Tel-to-IP Routing table.
● By default, the device applies telephone number manipulation (if configured) only
after processing the routing rule. You can change this and apply number
manipulation before processing the routing rule (see the RouteModeTel2IP
parameter).
● By default, if the device receives a REFER message, it forwards the message to
the destination specified in the message. Alternatively, if you want the device to
search again for a matching routing rule in the Tel-to-IP Routing table and to then
forward the REFER message to the destination of the matched rule, you need to
configure the [SIPReRoutingMode] parameter to [2].
● When using a proxy server, it is unnecessary to configure routing rules in the Tel-to-
IP Routing table unless you require one of the following:
✔ Alternative routing (fallback) when communication with the proxy server fails.
✔ IP security, whereby the device routes only received calls whose source IP
addresses are configured in the table. Enable IP security using the
SecureCallsFromIP parameter.
✔ Filter Calls to IP feature. The device checks the table before a call is routed to
the proxy server. However, if the number is not allowed (i.e., the number is not
specified in the table or a Call Restriction routing rule is configured), the call is
rejected.
✔ Obtain different SIP URI host names (per called number).
✔ Assign IP Profiles to calls.
✔ For the table to take precedence over a proxy server for routing calls, you need
to configure the PreferRouteTable parameter to 1. The device checks the
'Destination IP Address' field in the table for a match with the outgoing call; a
proxy is used only if a match is not found.
The following procedure describes how to configure Tel- to-IP routing rules through the Web
interface. You can also configure it through ini file [Prefix] or CLI (configure voip > gateway
routing tel2ip-routing).
➢ To configure Tel-to-IP routing rules:
1. Open the Tel-to-IP Routing table (Setup menu > Signaling & Media tab > Gateway folder >
Routing > Tel > IP Routing).
- 584 -
