CHAPTER25 Routing
Mediant 1000 Gateway & E-SBC | User's Manual
â– Enables Least Cost Routing (LCR), and defines default call cost (highest or lowest) and
average call duration for Tel-to-IP routing rules that are not assigned LCR Cost Groups. The
default call cost determines whether matched routing rules that are not assigned a Cost Group
are considered as a higher or lower cost route compared to other matching routing rules that are
assigned Cost Groups. If you disable LCR, the device ignores the Cost Groups assigned to
Tel-to-IP routing rules in the Tel-to-IP Routing table. LCR is applicable only to Tel-to-IP routing.
The following procedure describes how to configure Routing Policy rules through the Web interface.
You can also configure it through ini file [GwRoutingPolicy] or CLI ( configure voip >
gateway routing gw-routing-policy).
➢ To edit the Routing Policy rule:
1. Open the Routing Policies table (Setup menu > Signaling & Media tab > Gateway folder >
Routing > Routing Policies).
2. Click New; the following dialog box appears:
3. Configure the Routing Policy rule according to the parameters described in the table below.
4. Click Apply.
Table 25-5: Routing Policies Table Parameter Descriptions
Parameter Description
'Index'
[GwRoutingPolicy_Index]
(Read-only) Displays the index number of the table row.
'Name'
name
[GWRoutingPolicy_
Name]
Defines a descriptive name, which is used when associating the
row in other tables.
The valid value is a string of up to 40 characters.
The default value is "GwRoutingPolicy".
'LDAP Servers Group
Name'
ldap-srv-group-
name
[GWRoutingPolicy_
LdapServersGroupName]
Assigns an LDAP Server Group to the Routing Policy. IP-to-Tel
and Tel-to-IP routing rules that require LDAP-based routing
(and/or Call Setup Rules) use the LDAP server(s) assigned to the
LDAP Server Group.
By default, no value is defined.
For more information on LDAP Server Groups, see Configuring
LDAP Server Groups.
- 599 -
