CHAPTER26 Manipulation
Mediant 1000 Gateway & E-SBC | User's Manual
➢ To configure a redirect number manipulation rule:
1. Open the required redirect number manipulation table (Setup menu > Signaling & Media tab
> Gateway folder > Manipulation > Redirect Number Tel > IP or Redirect Number IP >
Tel).
2. Click New; the following dialog box appears (e.g., Redirect Number Tel-to-IP table):
3. Configure a manipulation rule according to the parameters described in the table below.
4. Click Apply.
Table 26-5: Redirect Number Manipulation Tables Parameter Description
Parameter Description
General
'Index'
[_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
'Name'
manipulation-name
[_ManipulationName]
Defines a descriptive name, which is used when associating the
row in other tables.
The valid value is a string of up to 40 characters.
Match
'Destination Phone
Pattern'
dst-pattern
[_DestinationPrefix]
Defines the destination (called) telephone number.
You can use special patterns (notations) to denote the number.
For example, if you want to match this rule to a number whose
last four digits (i.e., suffix) are 4 followed by any three digits (e.g.,
4008), then configure this parameter to "(4xxx)". For available
patterns, see Patterns for Denoting Phone Numbers and SIP
URIs on page1086.
The default value is the asterisk (*) symbol, meaning any
destination number.
Digital interfaces:For manipulating the diverting and redirected
numbers for call diversion, you can use the strings "DN" and
"RN" to denote the destination prefix of these numbers. For more
information, see Manipulating Redirected and Diverted Numbers
for Call Diversion.
'Redirect Phone Pattern'
redirect-pattern
[_RedirectPrefix]
Defines the redirect telephone number.
You can use special patterns (notations) to denote the number.
For example, if you want to match this rule to a number whose
last four digits (i.e., suffix) are 4 followed by any three digits (e.g.,
4008), then configure this parameter to "(4xxx)". For available
patterns, see Patterns for Denoting Phone Numbers and SIP
URIs on page1086.
- 624 -
