CHAPTER30 SBC Overview
Mediant 1000 Gateway & E-SBC | User's Manual
Figure 30-1: General Stages of OAuth-based Authentication
The main configuration required for OAuth-based authentication, includes the following:
â– Configuring a Remote Web Service to represent the OAuth Authentication server
â– Configuring the source IP Group (client) to authenticate by an OAuth Authorization server
The following provides a step-by-step example of configuring OAuth authentication.
➢ To configure OAuth-based authentication:
1. Open the Remote Web Services table (see Configuring Remote Web Services on page243),
and then configure a Remote Web Service to represent the OAuth Authentication server:
Parameter Value Comment
'Name' "OAUth-Server" Any descriptive name.
'Type' General -
'Path' "auth/realms/demo/protocol/openid-
connect/token/introspect"
Relative URL for the
introspection service on the
server.
'Username' "device234" Username that the device uses
for authenticating the HTTP
POST introspection request
which it sends to the OAuth
server.
'Password' "12abMt" Password that the device
uses for authenticating the
HTTP POST introspection
request which it sends to the
OAuth server.
2. Select the Remote Web Service that you configured in Step 1, click the HTTP Remote Hosts
link located below the table, and then configure an HTTP Remote Host:
Parameter Value Comment
'Address' "oauth.example.com" Address of the Authentication server.
'Port' "443" Port number of the Authentication
server.
- 743 -
