CHAPTER34 Routing SBC
Mediant 1000 Gateway & E-SBC | User's Manual
● The Classification table is used only if classification by registered user in the
device's users registration database or by Proxy Set fails.
● If the device receives incoming calls (e.g., INVITE) from users that have already
been classified and registered in the device's registration database, the device
ignores the Classification table and uses the Routing Policy that was determined
for the user during the initial classification process.
The following procedure describes how to configure Routing Policies rules through the Web
interface. You can also configure it through ini file [SBCRoutingPolicy] or CLI (configure voip
> sbc routing sbc-routing-policy).
➢ To configure a Routing Policy rule:
1. Open the Routing Policies table (Setup menu > Signaling & Media tab > SBC folder >
Routing > Routing Policies).
2. Click New; the following dialog box appears:
3. Configure the Routing Policy rule according to the parameters described in the table below.
4. Click Apply.
Table 34-4: Routing Policies table Parameter Descriptions
Parameter Description
General
'Index' Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
'Name'
name
[SBCRoutingPolicy_
Name]
Defines a descriptive name, which is used when associating the
row in other tables.
- 797 -
