CHAPTER35 SBC Manipulations
Mediant 1000 Gateway & E-SBC | User's Manual
Parameter Description
'ReRoute IP Group'
re-route-ip-group-
name
[IPOutboundManipulation_
ReRouteIPGroupName]
Defines the IP Group that initiated (sent) the SIP redirect
response (e.g., 3xx) or REFER message. The parameter is
typically used for re-routing requests (e.g., INVITEs) when
interworking is required for SIP 3xx redirect responses or
REFER messages.
The default is Any (i.e., any IP Group).
Note:
■ The parameter functions together with the 'Call Trigger'
parameter (see below).
■ For more information on interworking of SIP 3xx redirect
responses or REFER messages, see Interworking SIP 3xx
Redirect Responses and Interworking SIP REFER
Messages, respectively.
Action
'Manipulated Item'
manipulated-uri
[IPOutboundManipulation_
IsAdditionalManipulation]
Defines the element in the SIP message that you want
manipulated.
■ [0] Source URI = (Default) Manipulates the source SIP
Request-URI user part.
■ [1] Destination URI = Manipulates the destination SIP
Request-URI user part.
■ [2] Calling Name = Manipulates the calling name in the SIP
message.
'Remove From Left'
remove-from-left
[IPOutboundManipulation_
RemoveFromLeft]
Defines the number of digits to remove from the left of the
manipulated item prefix. For example, if you enter 3 and the user
name is "john", the new user name is "n".
'Remove From Right'
remove-from-right
[IPOutboundManipulation_
RemoveFromRight]
Defines the number of digits to remove from the right of the
manipulated item prefix. For example, if you enter 3 and the user
name is "john", the new user name is "j".
'Leave From Right'
leave-from-right
[IPOutboundManipulation_
LeaveFromRight]
Defines the number of digits to keep from the right of the
manipulated item.
'Prefix to Add'
prefix-to-add
[IPOutboundManipulation_
Prefix2Add]
Defines the number or string to add in the front of the
manipulated item. For example, if you enter 'user' and the user
name is "john", the new user name is "userjohn".
If you set the 'Manipulated Item' parameter to Source URI or
Destination URI, you can configure the parameter to a string of
up 49 characters. If you set the 'Manipulated Item' parameter to
Calling Name, you can configure the parameter to a string of up
to 36 characters.
- 814 -
