DIOD-DS1 (DS1 DIOD Trunk)
Issue 4 May 2002
10-585555-233-123
Three trunk service states are specified by DS1 DIOD trunk maintenance:
Hardware Error Log Entries and Test to Clear
Val ues
out-of-service The trunk is in a deactivated state and cannot be
used for either incoming or outgoing calls.
in-service The trunk is in an activated state and can be
used for both incoming and outgoing calls.
disconnect (ready-for-service) The trunk is in an activated state but can only be
used for an incoming call.
Table 10-217. DS1 DIOD Error Log Entries
Error
Type
Aux
Data Associated Test
Alarm
Level
On/Off
Board Test to Clear Value
0
1
0 Any Any Any test trunk <grp>/<mbr>
1(a) 57408
1(a) 57487
57476
57477
57485
15(b) Any Port Audit and
Update Test (#36)
18(c) 0 busyout trunk
<grp>/<mbr>
WARNING OFF release trunk <grp>/<mbr>
130(d) None WARNING ON test trunk <grp>/<mbr>
257(e) 57392 DS1 CO Dial Tone
Seizure Test (#314)
MIN/MAJ
2
OFF
513(f) 57393 DS1 Tie Trunk
Seizure Test (#136)
MIN/MAJ
2
OFF
769(g) 57484
1025(h) 51200
1025 DS1 CO Dial Tone
Seizure Test (#314)
MIN/
WRN
3
OFF test trunk <grp>/<mbr> r 2
1281 Conference Circuit
Test (#7)
MIN/
WRN
3
ON test trunk <grp>/<mbr> l r 4
1537 NPE Crosstalk Test
(#6)
MIN/
WRN
3
ON test trunk <grp>/<mbr> l r 3
1793(i) test board PCSS l
2049(j) 57473
57474
57475
