Maintenance Object Repair Procedures
555-233-123
10-592 Issue 4 May 2002
Port Audit and Update Test (#36)
This test sends port level translation data from switch processor to the DS1
Interface circuit pack to assure that the trunk’s translation is correct. Translation
updates include the following data: trunk type (in/out), dial type, timing
parameters, and signaling bits enabled. The port audit operation verifies the
consistency of the current state of trunk kept in the DS1 Interface circuit pack and
in the switch software.
2000 ABORT Response to the test request was not received within the
allowable time period.
2100 ABORT System resources required for this test are not available.
1. Retry the command at 1-minute intervals a maximum of 5
times.
2053 ABORT At least one of the following errors is found on the DS1 circuit
pack:
1281—Loss of signal
1793—Blue Alarm
2049—Red Alarm
2305—Yellow Alarm
1537—Hyperactivity
Look for the above error types in the Hardware Error Log and
follow the procedures given in the appropriate DS1-BD or
UDS1-BD maintenance documentation for the listed error
types.
FAIL The NPE of the tested port did not conference the tones
correctly. This will cause noisy and unreliable connections.
1. Replace the circuit pack.
PASS The port can correctly conference multiple connections.
User-reported troubles on this port should be investigated by
using other port tests and by examining station, trunk, or
external wiring.
Table 10-219. TEST #7 Conference Circuit Test — Continued
Error
Code
Te s t
Result Description/Recommendation
Continued on next page
