ETH-PT (Control LAN Ethernet)
Issue 4 May 2002
10-741555-233-123
Error Log Entries and Test to Clear Value
Notes:
a. Error Type 1: Ethernet Local Looparound Test (#1278) failed.
1. Test the port (test port UUCSSpp long).
2. Refer to repair procedures for Test #1278.
b. Error Type 513: Link Integrity Inquiry Test (#1282) failed or CLAN port
detected loss of Ethernet link integrity.
Possible causes:
■ Cabling
■ Ethernet transceiver
1. Test the port (test port UUCSSpp long).
2. If the Link Integrity Inquiry Test (#1282) fils, refer to its repair
procedure.
Table 10-278. ETH-PT Error Log Entries
Error Type
Aux
Data Associated Test
Alarm
Level
On/Off
Board Test to Clear Value
0
1
1 Run the Short Test Sequence first. If all tests pass, run the Long Test Sequence. Refer to the
appropriate test description and follow the recommended procedures.
0 Any Any Any test port UUCSSpp s
1 (a) 0 Ethernet Local
Looparound
Test (#1278)
MINOR ON test port UUCSSpp l r 3
513 (b) 0 Link Integrity Inquiry
(#1282)
MINOR OFF test port UUCSSpp r 2
769 (c) 0 WNG OFF
1281 (d) 0
1537, 1538
(e)
Session Status Test
(#1286)
MINOR OFF
1793-1920
(f)
2305-2560
(g)
2561-2816
(g)
3329 (h) TCP/IP Ping Test
(#1281)
WNG OFF
