FW-DWNLD (Firmware Download)
Issue 4 May 2002
10-845555-233-123
Download image from support Web site
For the download, you need a temporary staging area to keep the firmware
images before uploading them to the source circuit pack. Although the download
is normally done from a PC, you can also use other servers, such as UNIX.
1. Go to the Avaya Customer Support Web site (http://support.avaya.com).
2. Select the Online Services link near the top left of the page.
3. Select Software/Firmware Downloads.
A page with a large table appears.
4. Find and click on the following table entry
Grouping Product Name Document Title
Communication Definity Enterprise Definity Firmware
Systems Communication Server(G3x) Downloads
5. The main DEFINITY Firmware Download page appears.
6. Select the circuit pack you want to upgrade, then the firmware images that
you need (there may be more than one, depending on the circuit pack).
For example, the tn2501ap_f05.bin filename is for the TN2501AP (VAL)
circuit pack.
7. Download the file to the directory from which you will launch the FTP
application.
Pre-download checks
At the SAT:
1. Type change permissions <login> and press
Enter.
Ensure that the Administer Features field is y on the Command
Permissions Categories screen.
2. Get the IP address for the source circuit pack either from the data systems
administrator or by typing the following SAT commands:
a. If you know the circuit pack address, type list configuration board
<UUCSS> and press
Enter.
If you do not know the circuit pack address, type list configuration
all and press
Enter.
Check that these ports are enabled:
■ Port 17 (C-LAN)
■ Port 33 (VAL)
b. Type display port <UUCSSpp> and press
Enter to obtain the data
module ID, where pp is the port number.
